TCM 0325

TCM 0650

TCM 1550

TCM 3100

TCM 5500

TCM 7900

TCM 028K

TCM 065K

TCM 230K

Max. Flow Rate (kg/h)

325

650

1550

3100

5500

7900

28000

65000

230000

Max. Flow Rate (kg/h)

3

6

15

30

55

79

280

650

2300

Basic Accuracy (%o.r.)

±0.1

Zero Stability (% f.s.)

±0.01

Repeatability (% o.r.)

±0.05

Density Measuring Range

0 - 2500 kg/m3, 2.5 g/cm3 (higher ranges on request)

Density Accuracy

±1.0 kg/m3, ±0.001 g/cm3 (special calibration on request)

Density Repeatability

±0.5 kg/m3, ±0.0005 g/cm3

Temperature Accuracy

±1 °C ±0.5 % of reading (±1.8 °F ±0.5 % of reading)

Temperature Repeatability

±0.2 °C (±0.36 °F)

Process and Ambient

Process Connections

female thread 1/2“

adaptors for flanges, dairy and tri-clamp

flanges EN1092, ANSI B16.5, DIN2512,

threaded tri-clamp

Max. Pressure Standard

(Option)

200 bar/2900 PSI

(345 bar/5000 PSI)

100 bar/1450 PSI

Pressure Drop at Max. Flow

for detail information please contact us

Process Temperature (non Ex)

-40 °C ... +100 °C (-40 °F ... +212 °F) (standard)

-40 °C ... +150 °C (-40 °F ... +302 °F) (optional)

-60 °C ... +200 °C (-76 °F ... +392 °F) (optional)

Process Temperature (Ex)

meter mount -40 °C ... +70 °C (-40 °F ... +158° F) (T4)

n/a

remote version -40 °C ... +70 °C (-40 °F ... +158 °F) (T4)

-40 °C ... +135 °C (-40 °F ... +275 °F) (T3)

-60 °C ... +200 °C (-76 °F ... +292 °F) (T2)

Process Temperature (Ex)

-40 °C ... +70 °C (-40 °F ... +158 °F)

Ambient Temperature

-40 °C .. . +100 °C (-40 °F ... +212 °F)

Electr. Connections Remote

screw type terminals

Electr. Connections Meter Mount

none (internally connected to the electronics)

Ingress Protection

IP65 (IP66/IP67 on request)

General

Tube Arrangement

2 serial

2 parallel

2 serial

2 parallel

2 parallel

2 parallel

2 parallel

2 parallel

2 parallel

Tube Inner Diameter

4 mm

4 mm

8 mm

8 mm

7 mm

9 mm

16 mm

28 mm

43 mm

Tube Material

1.4404 / AISI 316L

Housing Material

1.4404 / AISI 316L

1.4301 /

AISI 304

Dimensions

see drawings
